mtu 12V 183 YACHT ENGINE

Technical Data of 12V 183

Model:

12V 183 TE 94

Engine power output:

970 kW (1320 hp)

Output per cylinder:

81 kW (110 hp)

Maximum torque:

4030 Nm at 2300 min-1

Rated speed:

2400 rpm

Bore:

128 mm

Stroke:

142 mm

Cylinder capacity:

1,83 dm3

Total engine capacity:

21,9 l

Overall dimensions:

1944 x 1370 x 1215 mm (LxWxH)

Weight incl. mountings, dry:

1930 kg

Power-to-weight ratio:

1,99 kg/kW

Fuel consumption at full power and within IMO emissions limits :

225 g/kWh

Aspiration:

Intercooled sequential turbocharger system
